Openbox S3 mini

Brand: ABC

Choose packing size : CHOOSE BIGGER PACK SIZE TO GET THE LOWEST PRICE
Price per unit:
Total price:
Price is excluding VAT !
€ 47,00

Openbox S3 mini , DVB-S2 Mini Receiver

Features of the Receiver

  • MPEG4/MPEG2 HD/SD, DVB-S/DVB-S2 standards compatibility
  • Full HDTV receiver with Time Shift function
  • Recording and playback in external USB-disc or Flash-drive (USB 2.0)
  • Multi-satellite rapid search
  • Input frequency range 950-2150 MHz
  • Bit rate range 1 - 90 Msps
  • Demodulation QPSK, 8 PSK
  • Multipurpose input SCPC and MCPC in C/Ku band
  • Rapid channel switch
  • DiSEqC 1.0, 1.1, 1.2 and USALS protocols support
  • Possibility to separate Time Shift and Recording functions using different USB storage devices.
  • Complete TV Guide (EPG)
  • Full channel viewing system (broadcasting standart, exact symbol rate, video and audio bitrates, presence and description of CAS)
  • 2*USB 2.0 Host port (up to 4 devices per USB Hub)
  • Multimedia files playback XViD, DivX, MKV etc
  • MP3-player and JPEG-viewer
  • Full-colour graphical user menu (interface) in 720P resolution
  • Built-in file manager which allows to manage multimedia files in connected USB storage devices with possibility to rename / copy / delete files and create new folders (sections)
  • The most handy channel editor (move / delete / rename / sorting)
  • 12 favourite channels lists (favourites) with 500 channels per list
  • Channel Blocker Parental Control Tool
  • 1 smart-card slot
  • Optical DV output S/PDIF
  • Dual video output with different screen resolutions (1080P + 576 l) which allows you to display two video signal (analog and digital) at the same time with different screen resolutions
  • CSVBS (composite) video and audio output to TV via mini Jack connector AV OUT.
  • Possibility to change the color palette of the DV output (RGB / YCBCR modes)
  • Possibility to update software and edit / update / save the channel list using USB andRS-232 ports
  • Different USB storage devices and multiplexers compatibility
  • Multiuser interface OSD for (11 languages)
  • "Hidden" subtitles system support via predetermined teletext page number
  • Support USB Wi-Fi dongles.
