Amiko Micro HD SE

Brand: Amiko

Choose packing size : CHOOSE BIGGER PACK SIZE TO GET THE LOWEST PRICE
Price per unit:
Total price:
Price is excluding VAT !
€ 33,00

  • Compact design
  • Mountable on TV’s back, or on wall
  • External IR sensor (included in the package)
  • Embedded card reader
  • Two High speed USB 2.0 connections
  • Multimedia playback
  • Stream TV & Radio channels to your Android devices via local network!
  • Ethernet & USB WiFi connection support (Ralink RT5370 chip)
  • YouTube, Weather Forecast & RSS Reader functions
  • Full HD 1080p output through HDMI
  • Jack type analogue RCA output
  • DiSEqC 1.0, 1.1, 1.2 and USALS Compatible
  • Easy software upgrades through USB or network
  • Easy database & settings transfers through USB
  • Less than 0.5W power consumption in stand-by mode
  • 12V DC power - ideal for camping and traveling


PRODUCTION OF AMIKO MICRO HD SE FINISHED, PLEASE CHOOSE REPLACEMENT ON BOTTOM OF SITE


System Resources

Main Processor: 400MHz based CPU
Flash Memory: 64MBits
DDR RAM: 1024Mbits

MPEG TS A/V Decoding

Transport Stream: MPEG-2, MPEG-4 (H.264)
Input Rate: Max.120Mbit/s
Aspect Radio: 4:3, 16:9, Letter Box
Video Decoding: MPEG-2, MP@ML, MPEG-4 part 10/H264
Video Resolution: 720*480p/i, 720*576p/i, 1280*720p, 1920*1080p/i
Audio Decoding: MPEG-1 layer I/II, MPEG-2 layer II, Dolby Digital
Audio Mode: Left / Right / Stereo/ Mono
Sampling Rate: 32, 44.1 and 48KHz

A/V & Data Input/Output

AV OUT: Video CVBS output, Audio L/R output (Jack Type)
LAN: RJ-45 Ethernet Connection
RS-232C: Transfer rate 115.2Kbps, (Jack Type)
IR IN: External IR Connection (Jack Type)
USB: Two USB 2.0 slots
HDMI: VER1.3, Type A, Dolby Digital Bit-Stream Output
Tuner & Demodulation

Tuner Type: DVB-S2
Input Connector: F-type, Connector, Female
Signal Level: -65 to -25 dBm
LNB Power: Vertical: +13V/+14V,
Horizontal: +18V/+19V
Current: Max. 350mA
Overload Protection
22K Tone Frequency: 22±1KHz
DiSEqC Control: Version 1.0, 1.1, 1.2, USALS
Demodulation: QPSK, 8PSK
Input Symbol Rate: 2-45 Mbps,
FEC: 1/2, 2/3, 3/4, 5/6, 7/8 and Auto

Physical Specifications

Size[W*H*D]: 75 mm * 115 mm * 22 mm
Net Weight: 0.25 Kg
Operation Temperature: 0°C~+45°C
Storage Temperature: -10°C~+70°C
Storage Humidity: 5%~95% RH (Non-Condensing)
