EMP Centauri DiSEqC switch S2/1PCPpos-W1 ( p.162 TW pos )

3in/1out DiSEqC 2.0 switch for 2 satellite positions and 1 subscriber, equipped with combiner for terrestrial band. It is designed for switching between 2 LNBs, with using command Position (type S2/1PCPpos-W1, receiver setting A/B) or Option (type S2/1PCPopt-W1, receiver setting A/C). For common use is version Position preferred, for switching between Monoblock and other LNB is version Option required.
The product allows joining terrestrial band to common downlead.

Parameter Condition Value
Frequency range LNB inputs 950-2300 MHz
Terr. input 5-862 MHz
Output 950-2300 MHz
Control S2/1PCPpos-W1 DiSEqC 1.0 (2.0) command "Position"
S2/1PCPopt-W1 DiSEqC 1.0 (2.0) command "Option"
Insertion loss Sat. 5 dB avg
Terr. 2 dB avg
Sat. inputs isolation 25 dB min
Power consumption From receiver 30 mA (18 V) + LNB
DC current pass 400 mA max
Dimensions (w,d,h) 8.2 x 7.7 x 2.3 cm
Temperature range -30 ~ +70 °C
